Curt 17500 TruTrack Weight Distribution System - 72.1685

Name: Curt 17500 TruTrack Weight Distribution System
Brand: Curt Manufacturing
SKU: 72.1685
Price: 609.9500 USD
Availability: InStock

Curt 17500 TruTrack Weight Distribution System Image 2

$871.87

$609.95

Sale Prices Shown are Valid Until 09/12/26.

PRODUCT DESCRIPTION

Curt 17500 TruTrack Weight Distribution System

Item 72.1685 | MFR# 17500

The CURT TruTrackr weight distribution hitch provides superior towing control with integrated four-point sway control and trunnion-style spring bars. Rated for up to 10,000 lbs. gross trailer weight and 1,000 lbs. tongue weight, it includes a 2-5/16-inch hitch ball and a 12-inch adjustable shank for easier installation and proper trailer leveling. The trailer-mounted design helps simplify hookup while improving towing stability.

Features:

1,000 lb. Tongue Weight Capacity
10,000 lb. Gross Trailer Weight Rating
Integrated Four-Point Sway Control
Includes 2-5/16 Inch Hitch Ball
12-Inch Adjustable Shank
Fits 2-Inch Receiver Hitches

Please Note:

Towing capacity is limited by the lowest-rated towing component.

The CURT 17500 TruTrack weight distribution system uses spring bars for using the trailer tongue weight and spreading it across the axles of the trailer-vehicle combination. The TruTrack is connected to the frame of the trailer with adjustable, heavy-duty support brackets, which will hold the bars in place vertically and laterally. The angle of regular spring bars goes from side to side, but with the integrated sway control arms this movement is restricted and ensures that the trailer is aligned perfectly. There is also a unique cam and spring system, which builds up pressure and ensures that swaying stops actively, and it relaxes for smoother turns. The hardened parts of the weight distribution system are also less likely to suffer from wear and tear. Another great aspect of the CURT 17500 TruTrack weight distribution system is that it is extremely easy to set up. This is mainly down to the 6 preset holes and interlocking nuts that offer specific tilt angles and offer a simpler adjustment method. The hitch head doesn't need to be disassembled for adjustments, unlike other weight distribution hitches, and the interlocking nuts can be accessed easily, which makes adjustment easy and faster installation. Apart from the easy setup and integrated sway control, the CURT 17500 TruTrack provides superior quality, which makes it the best choice for heavy-duty trailers, car haulers, livestock trailers and campers. You also get a limited lifetime warranty with this exceptional hitch.

More Details EXPAND

Manufacturer

Curt Manufacturing

Manufacturer Numbers

17500, 72-1685

UPC List

612314175000

Popularity

6598

Freight Charge Residential

299

Freight Charge Commercial

299

Features

Integrated sway control actively resists sway and levels the vehicle and trailer
Adjustable brackets provide fixed support unlike spring bar chain models
Welded head with cast pieces provides solid spring bar attachment
Uses spring & cam system with hardened components, instead of metal friction
Brackets use friction to resist lateral movement, replacing a sway control

Specifications

Trunnion Bar Weight Distribution Hitch
Gross Trailer Weight (GTW): 10,000 LB
Finish: Carbide Black Powder Coat
Color: Black
Warranty: Limited Time Warranty
